This 8 tall 360-degree radial flow air filter features a 5-1/2 Inch flange and our oil-free Pro Dry S media with three layers of synthetic media for maximum convenience. Its progressive layering provides great filtration efficiency and dust holding capacity, while not requiring the use of oils. This media is best suited for street and light off-road use.
Its inverted top makes for more filter surface area, resulting in longer service intervals. The included massive air filter is surrounded by an open-element Xlpe (cross-linked polyethylene) polymer housing that minimizes warm engine air for maximum performance. Its open design allows for easy viewing of the air filter and delivers an aggressive Air Intake sound.This system features a high quality, computer-designed, dyno-tuned intake tube to achieve maximum power gains while maintaining a perfect fit.
Its Xlpe material is heat soak resistant and extremely durable. This is a direct fit intake system that utilizes factory mounting points and requires no cutting or modifications. All necessary clamps and hardware are included.
The filter is mounted on a 3-angle adapter for maximum airflow and convenience. This innovative design allows for easy filter servicing, by loosening only one clamp.
Features and Benefits:
- The Stage-2's oversized filter and open design not only draws attention, but also unleashes an aggressive turbo whistle sound when your under power.
- Open-Element Design Showcases the Air Filter and Delivers an Aggressive Air Intake Sound
- 3-Angle Filter Adapter Allows for Maximum Flow and Easy Installation/Maintenance
- Washable and Reusable Pro Dry S Air Filter for Maximum Convenience
- Utilizes Factory Mounting Locations for a Fast and Easy Installation (Roughly 30 Minutes)
Details:
- Air Box Type: Open
- Air Filter Flange Inside Diameter: 5.5 Inch
- Air Flow Gain: 45 Percent
- Air Flow Rate: 690
- Air Intake Tube Color: Black
- Air Intake Tube Material: Cross-linked Polyethylene
- Coupler Color: Black
- Coupler Included: Yes
- ECU Tuning Required: No
- Emission Code: 4
- Filter Color: Gray
- Filter Included: Yes
- Filter Material: Non-woven Synthetic
- Fuel Type: Diesel
- Grade Type: Performance
- Heat Shield Included: Yes
- Horse Power Increase: 16
- Liter: 6.7 Liter
- Mass Air Flow Sensor Mounting Provision: Yes
- Modifications Required: No
- Mounting Hardware Included: Yes
- Oiled or Dry Media: Dry
- Series: Magnum Force
- Torque Increase: 31 ft-lbs
- Warranty: 2 Year
Applications:
- Ford Diesel Trucks 11-16 V8-6.7L (td)
